Skyjack SJ3220/26

Skyjack
Skyjack
Skyjack
Skyjack
Make Skyjack
Model SJ3220/26
Type DC Electric Scissors

How can we help?


Description

Industry Leaders

Skyjack electric scissor lifts have been recognized as an industry leader for over a decade. Our DC scissor lifts are ideal for indoor work where accuracy and precision turns around sensitive material is critical.

Models

Overall Specifications
SJ3220 SJ3226
Work Height 25’ 6” (7.77 m) 31' 7" (9.63 m)
Raised Platform Height 19’ 6” (5.95 m) 25’ 7” (7.79 m)
Lowered Platform Height 39” (0.99 m) 46” (1.17 m)
Overall Width 32” (0.81 m) 32” (0.81 m)
Overall Length 91.6” (2.32 m) 91.6” (2.32 m)
Stowed Height (Rails Up) 83” (2.10 m) 90” (2.29 m)
Stowed Height (Rails Down) 69” (1.75 m) 76” (1.93 m)
Platform Width (Inside Dimension) 28” (0.71 m) 28” (0.71 m)
Platform Length (Inside Dimension) 83” (2.11 m) 83” (2.11 m)
Extension Deck (Roll Out) 3’ (0.91 m) 3’ (0.91 m)
Wheelbase 69” (1.75 m) 69” (1.75 m)
Weight 3,917 lbs (1,776 kg) 4,190 lbs (1,900 kg)
Gradeability 25% 25%
Turning Radius (Inside) 43” (1.09 m) 43” (1.09 m)
Turning Radius (Outside) 104” (2.64 m) 104” (2.64 m)
Lift Time (With Rated Load) 28 sec 47 sec
Lower Time (With Rated Load) 24 sec 41 sec
Drive Speed (Stowed) 2.4 mph (3.9 km/h) 2.4 mph (3.9 km/h)
Drive Speed (Raised) 0.6 mph (1.0 km/h) 0.6 mph (1.0 km/h)
Maximum Drive Height Full Height Full Height
Capacity 900 lbs (408 kg) 500 lbs (227 kg)
Capacity (Overall) 600 lbs (272 kg)
Distributed Capacity (Main Platform) 250 lbs (113 kg)
Distributed Capacity (Extension Deck) 300 lbs (136 kg) 250 lbs (113 kg)
Local Floor Load (With Rated Load) 109 psi (749 kPa) 104 psi (718 kPa)
Overall Floor Load (With Rated Load) 248 psf (1209 kg/ m2) 241 psf (1177 kg/ m2)
Maximum # of Persons 2 2
Tire Type Solid, N/M Solid, N/M
Tire Size 16 x 5 x 12 16 x 5 x 12

Features

  • 6’ (1.8 m) POWERED EXTENSION DECK
  • FLASHING LIGHT
  • EXTENDED WARRANTIES
  • BATTERY OPTIONS
  • AC INVERTER
  • FULL HEIGHT SPRING HINGED GATE
  • TOOL CADDY
  • DC HEAVY DUTY PIPE RACK
  • SGLE
  • BOARD CARRIER
  • BIO OIL
  • EE RATING PACKAGE
  • NON DESTRUCTIVE TESTING
  • DC LIGHT DUTY PIPE RACK
  • DUAL FLASHING LIGHTS
  • ELEVATE
